Tiny Call Light Kit (DIY)

Description

Designed as a DIY kit to provide call light notification for Clear-Com style intercom systems, the Tiny Call Light (envisioned and designed by Scott Helmke) provides simple visual indication in a tiny package.  It’s perfect for stashing in convenient nooks around FOH (or wherever your workspace), and much less cumbersome than other call lights on the market.

The DIY kit includes all necessary on-board and off-board components, as well as basic instructions for assembly.  A pre-assembled version of the kit is also available here.

Parts list:

1x 220 Ω (R1)
1x 47K Ω (R2)
1x 10K Ω (R3)
1x KSP2222 (Q1)
13x LED (D1-13)
1x terminal block (J1)
1x 3′ mic/line cable
1x XLR female connector
1x Magnetic backing material

For more information, visit tcfurlong.com/tiny-call-light
